11 - 3
IPN 074-397-P1G
HAPSITE Smart Operating Manual
Figure 11-3 Error Information Button
The order of pages that appear in Wizard mode for different collection and analysis
modes are listed in Table 11-1.
Development of a Method starts with a default set of components. The default
settings are extracted from the software when editing a New Method. A New
method is also supplied with a default Method filename, which can be changed on
any page of the editor. The editor will automatically increment the default name with
each successful launch and exit of the editor, provided the resulting Method is
saved.
The remainder of section 11.2, Description Page, on page 11-3 and all subsections
will describe and define the Method Editor interface and parameters used to create
a HAPSITE Method File. A HAPSITE Method File can be deployed in numerous
configurations; however, development of the complete method is done only on the
PC and is then downloaded to the HAPSITE.
11.2 Description Page
The first page displayed in the Method Editor is the Description Page (Figure
11-4), which provides selections for the Mode of Analysis and Collection Mode.
These selections determine the default content of the remaining Editor pages and
the content of the Method file itself.
NOTE: A Method File ends with a file extension of.mth.
Table 11-1 Method Editor Page Flow
GC/MS Full
Scan
GC/MS SIM Survey Full
Scan
Survey SIM
Description Description Description Description
Startup Startup Startup Startup
Inlet Inlet Tune Tune
Tune Tune Full Scan SIM
Full Scan SIM Search Search
Search Search Data Data
Data Data Summary Summary
Summary Summary
