7 - 9
IPN 074-397-P1G
HAPSITE Smart Operating Manual
7 Highlight default.tun. Click OK. See Figure 7-15.
NOTE: This will overwrite the
default.tun file. See section 10.3 on page
10-11 for information on transferring files to the PC if saving a copy of
this file is desired prior to overwriting it.
Figure 7-15 Save "default.tun"
8 Replace the existing default.tun file when prompted.
9 Reboot HAPSITE from the Front Panel Exit menu. Refer to section 3.10.4,
Rebooting the HAPSITE, on page 3-52 for more information on how to reboot
the HAPSITE.
10 If the HAPSITE fails to tune after steps 1-9 have been performed, see section
7.6, Performing Manual Tune, on page 7-25 for information on performing a
manual tune.
7.5 Manual Tune Settings and Controls
Manual Tune is run from the laptop computer The Manual Tune screen can be
accessed by selecting the Tune icon from the System Setup screen, or by
highlighting the HAPSITE Icon, clicking the right mouse button and selecting Tune.
When the Manual Tune screen is selected the system will initialize all of the
controls necessary to perform a Tune (e.g., turning on the filament, multiplier and
calibration/tune gas supply).
NOTE: Manual Tune is only available in Advanced user mode.
See Figure 7-16 for a typical Manual Tune screen.
