5 - 24
IPN 074-397-P1G
HAPSITE Smart Operating Manual
The concentrator feature is designed to enhance
HAPSITE sensitivity when analyzing low concentration
samples. The accumulated sample VOCs are transferred
from the concentrator adsorbent bed to the HAPSITE as
a concentrated sample. Care should be taken to avoid
overloading the HAPSITE and causing excessive
carryover of VOCs in subsequent runs.
5.4.1 Quick Reference SOP — Tri-Bed Concentrator Cleanout
1 Start Smart IQ and double-click Run Method.
2 Double-click the GCMS folder.
3 Double-click the Concentrator folder.
4 Highlight 3 min Carbon Conc Cleanout and press OK.
5 Wait for heaters to reach set temperatures.
6 When prompted press RUN.
HINT: If the TIC_Max count is less than 500,000 at the end of this run, proceed to
the Air 15 min Carbon Conc method. If the TIC_MAX count is greater than
500,000, rerun the 3 min Carbon Conc Cleanout method.
5.4.2 Quick Reference SOP — Tri-Bed Concentrator Method
1 The 3 min Carbon Conc Cleanout method must be run prior to this method.
Refer to Section 5.4.1, Quick Reference SOP — Tri-Bed Concentrator
Cleanout, on page 5-24.
2 Start Smart IQ and double-click Run Method.
3 Double-click the GCMS folder.
4 Double-click the Concentrator folder.
5 Highlight Air 15 min Carbon Conc method and press OK.
6 Wait for heaters to reach set temperatures.
7 When prompted press RUN.
8 Hold the probe over the sample for both the one minute LinePurge and the one
minute Concfill event.
9 Wait for run to complete to view results.
