2 - 43
IPN 074-397-P1G
HAPSITE Smart Operating Manual
2.11.2.2 Battery Charger Connections and Startup
Plug the power cord into the connector at the right rear of the Battery Charger, then
into a grounded outlet. The ON light will illuminate. (The Battery Charger does not
have a power switch).
As the Battery Charger performs a self-test, all the indicators will turn amber, then
all will turn green (except that the indicator for any bay already containing a battery
will turn red at this step) then all but the ON indicator will extinguish. No further
warm-up is required; it is ready to charge batteries.
2.11.2.3 Loading the Battery Charger
The receptacles of the Battery Charger are identical and batteries in any state of
charge can be connected. Place each battery to be charged in one of the charging
receptacles. The respective light will illuminate green and charging will commence
immediately.
Do not use excessive force when placing the battery in
the Battery Charger.
Do not charge batteries in a moving vehicle.
2.11.2.4 Understanding the Battery Charger Indicators
Each battery receptacle is associated with an indicator light which can be
illuminated in any of three colors. Their interpretation is:
Green . . . . . . . . . . . . . . . . . . . . . . . . The battery is being charged. This will
continue for 15 hours or less. If a severely
discharged battery is inserted, the green light
will flash. If it flashes for more that 10
minutes, the battery will not accept a charge
and should be replaced. The actual state of
the battery charge can be assessed by using
the TEST button on the battery.
Amber . . . . . . . . . . . . . . . . . . . . . . . The battery is fully charged. The rate of
charge has been reduced to a maintenance
level. The battery can be left this way
indefinitely.
