2 - 47
IPN 074-397-P1G
HAPSITE Smart Operating Manual
2.12.2.2 Care of the Backpack
Avoid exposing the backpack to solvents and other active chemicals.
Avoid storing the backpack to direct sunlight.
Wash the backpack as necessary with water and mild soap.
Do not store the backpack with the fabric in contact with
concrete, as the moisture and chemicals in concrete can
weaken nylon.
2.13 Hot Swap Cable (IPN 930-246-G1)
The Hot Swap Cable is used to provide an external power source for the
HAPSITE®. When connected between an external battery and the 24 V(dc) power
port on the HAPSITE, the Hot Swap Cable permits changing the internal battery
without the loss of power to the HAPSITE.
2.13.1 Connecting The Hot Swap Cable
Do not use the Hot Swap Cable in the rain.
1 Plug the "L" connector into the back of a charged battery. See Figure 2-60.
Figure 2-60 Hot Swap Cable Components
“L”
Battery
Power
Connector
Connector
WARNING
Do not use if
the "L" connector
is broken.
