2 - 48

IPN 074-397-P1G

HAPSITE Smart Operating Manual

WARNING

Risk of electrical shock. Be careful when using the Hot

Swap Cable. Connect the Hot Swap Cable L connector to

the battery first, then plug the power connector into the

HAPSITE 24 V (dc) power port.

2 Plug the power connector into the 24 V(dc) power port on the HAPSITE. The

discharged internal battery can now be replaced. After replacing the internal

battery, disconnect the Hot Swap Cable. See Figure 2-61

CAUTION

Do not open the HAPSITE front panel in a contaminated

environment.

Figure 2-61 Power Connector

HAPSITE

24 V(dc)

Power

Port
