14 - 25
IPN 074-397-P1G
HAPSITE Smart Operating Manual
The Service Module should be stored in a clean and dry
area. Avoid storing the Service Module in areas which are
outside the temperature range of 40 to 95 °F.
14.11 When Power to the Service Module is Lost
The Service Module has an onboard battery which allows the Service Module to
close the HAPSITE Interconnect Plug and shut down the pumps properly in case
of a sudden loss of supplied power. This happens automatically in order to
preserve the vacuum in the HAPSITE Mass Spectrometer manifold, and to protect
the Service Module pumps from being damaged.
When power is restored, the HAPSITE and Service Module will need to be
attached again before the Service Module will provide proper vacuum for the
HAPSITE. Refer to section 14.7, Attaching the HAPSITE to the Service Module, on
page 14-12.
NOTE: Refer to Chapter 15, Maintenance for additional information on using the
Service Module to perform maintenance on the HAPSITE.
