14.2 Service Module Input Power
Service Modules are available in either 110/220 V(ac) (IPN 930-202-G1) or
24 V(dc) (IPN 930-202-G3) input power models. With the exception of input power,
both models are identical.
14.2.1 Service Module 110 / 220 V(ac) Input
The 110/220 V(ac) model operates from 110/220 V(ac) line voltage. See Figure
14-1.
Figure 14-1 Service Module 110 / 200 V(ac) Version
14.2.2 Service Module 24 V(dc) Input
The 24 V(dc) model operates from an external 24 V(dc) power supply. See Figure
14-2.
Figure 14-2 Service Module 24 volts
