2 - 23
IPN 074-397-P1G
HAPSITE Smart Operating Manual
Figure 2-32 Cleaning the Service Module Rubber O-ring using a Lint-free Wipe
After cleaning the rubber o-ring, make sure there are no cuts on it. Also look for any
visible cracking of the o-ring. If the o-ring is damaged, the o-ring may need to be
replaced. Ensure the o-ring is completely seated in the grove.
2.7.2 Placing the HAPSITE on the Service Module
Never operate the HAPSITE on the Service Module in a
moving vehicle.
Remove the yellow plastic protective cover from the bottom of the HAPSITE. The
yellow cover is shown in Figure 2-33.
NOTE: Store the yellow cover in a clean dry place, where it will be easily
accessible for later use. This protective cover keeps dust and debris out of
the HAPSITE manifold connection.
The yellow plastic protective cover must be installed
during decontamination of the HAPSITE.
