2 - 36
IPN 074-397-P1G
HAPSITE Smart Operating Manual
2.9.5 Removing the Concentrator Tube
1 Open the front panel of the HAPSITE and remove the black cover labeled
Concentrator.
The elbow fittings and nuts may be hot. If necessary, let
the elbow fittings and nuts cool down before continuing.
2 Using the 7/16" open end wrench suppled by INFICON, loosen the nuts on the
top and bottom of the concentrator tube until the tube becomes free.
3 Lift the top elbow and gently angle the concentrator tube out of the fixture.
4 Remove the concentrator tube from the bottom elbow, being careful not to lose
the ferrules on the top and bottom.
5 Store the concentrator tube in a safe place for future use.
