2.12 Portable Accessories

Portability is an important HAPSITE feature. The following accessories facilitate

portability.

2.12.1 HAPSITE and Headspace Sampling System Strap

Attach the HAPSITE and Headspace Sampling System straps as illustrated below

in Figure 2-59:

Figure 2-59 Attaching the HAPSITE Strap

WARNING

Failure to connect strap as shown increases the risk of

strap failure possibly resulting in dropping the HAPSITE

and/or bodily injury.

HAPSITE

Or Sampling Accessory

Strap must be attached

to HAPSITE or Sampling

Accessory as shown.

Strap Eyelet

Strap
