13 - 16
IPN 074-397-P1G
HAPSITE Smart Operating Manual
13.3.4 Washing the HSS
The HSS is designed to be water resistant, but not water proof. The HSS can
withstand rainfall, but should be removed to a dry area as soon as possible. The
front door has a seal which prevents water from passing into the instrument when
the door is closed. There is also a seal around the entire instrument where the
headspace cover meets the base plate of the headspace. Proceed as follows to
wash the HSS.
WARNING - Risk Of Electric Shock
Be careful to avoid shock. Disconnect the Headspace
instrument from its power source before continuing.
Be careful to avoid burns if the surfaces are still hot.
The needle tip is sharp, be careful to avoid injury;.
1 Disconnect the HSS from the external power supply.
2 Remove the battery.
3 Remove all vials from the HSS heater wells (be careful of the sharp needle).
4 Disconnect the transfer line at the back of the HSS.
5 Close access doors.
6 Install the plugs.
7 Wash the instruments using a low pressure water stream or with a soft cloth or
paper towel and a mild soap. For washing, see section 13.3.3, Cleaning the
HSS Wells, on page 13-15.
NOTE: Solvents, abrasives, and strong soaps should not be used.
8 Rinse the HSS with clean water, using low water pressure (do not use a high
pressure washer).
9 Allow the HSS to dry thoroughly before reconnecting any power supply.
