Inficon HAPSITE Smart - 10.3 Transferring Files Between the HAPSITE and PC

10 - 11
IPN 074-397-P1G
HAPSITE Smart Operating Manual
10.2.3 Data Files
Data files are automatically saved to the HAPSITE hard drive and to the PC if the
PC is connected and running Smart IQ when the method finishes. To save these
files to the PC, use the Manage Files dialog to transfer the files from the HAPSITE
to the PC. For more information on transferring files, see section 10.3, Transferring
Files Between the HAPSITE and PC, on page 10-11.
10.2.4 Tune Files
Tune files are automatically saved to the HAPSITE hard drive. To save these files
to the PC, use the Manage Files dialog to transfer the files from the HAPSITE to
the PC. For more information on transferring files, see section 10.3, Transferring
Files Between the HAPSITE and PC, on page 10-11.
10.2.5 Report Files
Report files are automatically saved to the HAPSITE hard drive. To save these files
to the PC, use the Manage Files dialog to transfer the files from the HAPSITE to
the PC. For more information on transferring files, see section 10.3, Transferring
Files Between the HAPSITE and PC, on page 10-11.
NOTE: Report files are embedded in the data files so copying them to the PC is
not critical.
10.3 Transferring Files Between the HAPSITE and PC
Transfer of files between the HAPSITE and PC in the HAPSITE Smart IQ software
can be performed using Manage Files. To open the Manage File dialog, either right
click on a sensor icon then select Manage Files, or select a sensor then double
click on the Manage Files icon in the System Setup view. The Manage Files icon
is shown in Figure 10-15.
Figure 10-15 Manage Files Icon in System Setup View
The Manage Files dialog allows the transfer files directly from the HAPSITE to the
PC, or from the PC to the HAPSITE. The Manage Files dialog is shown in Figure
10-16.
NOTE: Data files cannot be copied from the PC to the HAPSITE.
