2 - 6
IPN 074-397-P1G
HAPSITE Smart Operating Manual
2.3.2 Remove Exhaust (Vent) Cap
The red exhaust (vent) cap is located on the right side of the HAPSITE near the
back. This exhaust (vent) cap must be removed
for the HAPSITE to function
properly. The HAPSITE is shipped with the cap removed. See Figure 2-9.
Figure 2-9 Exhaust Cap
Failure to remove the exhaust cap will cause the
HAPSITE to not operate properly.
Compounds sampled will vent into the room through the
exhaust. When sampling hazardous materials either
attach tubing and vent to a hood or attach an activated
charcoal filter.
