9 - 33
IPN 074-397-P1G
HAPSITE Smart Operating Manual
Clear NIST Grab file . . . . . . . . . . . . Clears the grab file of previous files.
Switch to NIST Program (F8). . . . . Starts the full NIST program and will place
any files that are in the grab file into the Spec
List, then begin analysis of them.
Search NIST/User (F7) . . . . . . . . . . Starts the NIST program and does searches.
Displays matches on the Scan /Spectrum
window and Control Panel.
Exit Search NIST/User (Alt+F7) . . . Exits the Search NIST/User database search
function.
Add to NIST User . . . . . . . . . . . . . . Add selected spectrum to a Search
NIST/User database.
Manage NIST User Database . . . . . Display, delete or plot entries in a Search
NIST/User database.
9.8.5 How to Grab Spectra/Utilize the Full NIST Program
The sequence of events required to utilize the full NIST program are:
1 Double-click on the peak in the TIC/RIC window for the NIST Full Program
analysis.
2 Place the cursor in the Spectrum window and RMB click. Select NIST >> Clear
NIST Grabfile
3 Place the cursor in the Spectrum window and RMB click. Select NIST >> Grab
Spectrum for NIST. See Figure 9-41.
Figure 9-41 Pop-Up WIndow, Grab Spectrum for NIST
4 After the spectrum has been grabbed, either:
press F8 to open the full NIST program.
select NIST >> Switch to NIST Program.
Once inside the NIST Program, the analysis will be performed. There are many
other features that the NIST program has to offer. See Figure 9-42.
