IPN 074-397-P1G

HAPSITE Smart Operating Manual

15.7.3 Part 2: Service Module Vacuum Interconnect (VI) Valve Cleaning

1 Remove the HAPSITE from the Service Module (see section 14.9, Physically

Removing the HAPSITE from the Service Module, on page 14-20).

2 On the underside of the Analytical Module remove the VI valve using the 1/4”

Allen wrench. See Figure 15-17.

Figure 15-17 Removing the VI Valve
