15 - 31
IPN 074-397-P1G
HAPSITE Smart Operating Manual
9 Replace the chain clamp insuring that the nut points to the left. Use the
torque wrench and tighten to 70 inch/ pounds or 8 Nm. See Figure 15-29.
Figure 15-29 Torquing Chain Clamp
DO NOT connect the black plug from the new NEG Pump
to the black socket at this time. This will avoid any
accidental heating of the NEG Pump until the system has
been leak checked and the NEG has been activated.
To Next Page
