12 SYSTem Subsystem
504 Keysight N8262A Programming Guide
Window/measurement setup
Upper window/upper measurement (UU)
Feed Gate 1 Channel A
Gate 1 primary channel
[a]
Measurement Avg Avg
Upper window/lower measurement (UL)
Feed DEF See Table 12-2
Measurement DEF See Table 12-22
Lower window/upper measurement (LU)
Feed Gate 1 Channel A See Table 12-22
Measurement Peak See Table 12-22
Lower window/lower measurement (LL)
Feed Gate 1 Channel A See Table 12-22
Measurement Pk-to-Avg See Table 12-22
[a] For further information refer to “Primary and Secondary Channels” on page 473.
Table 12-21 MPCA: Power meter presets: Window/Measurement settings (continued)
Function Setting
Single Channel Dual Channel
Table 12-22 MCPA: Power meter presets for secondary channel sensors
Function Secondary Channel Sensor
No Sensor Non P-Series Sensor P-Series Sensor
Display setup
Upper window UU single numeric Dual numeric Dual numeric
Lower window Dual numeric Dual numeric Dual numeric
Upper window/lower measurement (UL)
Feed DEF
Gate 1 primary channel
[a]
Gate 1 primary channel
[a]
(Channel A)
