3 WLAN Mode
3.6 Modulation Analysis Measurement
Remote
Command
[:SENSe]:EVM:TIME:RESult:SIG OFF | ON | 0 | 1
[:SENSe]:EVM:TIME:RESult:SIG?
Example
:EVM:TIME:RES:SIG ON
:EVM:TIME:RES:SIG?
Notes Available when Radio Std is 802.11n/ac/ah/af/ax/be
The result length is determined by decoding the HT-SIG symbols and using the HT Length field. The
value of Max Result Length specifies a maximum result length for the pulse; any pulse longer than that
will be treated as though that were the length of the pulse
Preset
OFF
State Saved Saved in instrument state
Range On|Off
Burst Power Meas Offset
To measure power of a specified period, this parameter specifies the measuring start
time of a burst.
Remote Command
[:SENSe]:EVM:TIME:BPOWer:OFFSet <time>
[:SENSe]:EVM:TIME:BPOWer:OFFSet?
Example
:EVM:TIME:BPOW:OFFS 1us
:EVM:TIME:BPOW:OFFS?
Dependencies Only available for 11n/ac/ax/be and 11agjp when radio std detection is auto
Preset
1us
State Saved Saved in instrument state
Min/Max -/+3 ms
Burst Power Meas Length
To measure power of a specified period, this parameter specifies the measurement
length.
Remote Command
[:SENSe]:EVM:TIME:BPOWer:LENGth <time>
[:SENSe]:EVM:TIME:BPOWer:LENGth?
Example
:EVM:TIME:BPOW:LENG 10us
:EVM:TIME:BPOW:LENG?
Dependencies Only available for 11n/ac/ax/be and 11agjp when Radio Std detection is auto
Preset
20us
State Saved Saved in instrument state
Min/Max 1us/6 ms
1011 WLAN Mode User's &Programmer's Reference
