3 WLAN Mode
3.9 Spectral Flatness Measurement
Remote Command
:INITiate:PAUSe
Example
:INIT:PAUS
Dependencies Not displayed in Modes that do not support Pausing.
Annotation Only on control
Remote Command
:INITiate:RESume
Example
:INIT:RES
Dependencies Not displayed in Modes that do not support Pausing.
Annotation Only on control
3.9.9.2 X Scale
This tab accesses controls that enable you to configure the Sweep and Control
functions of the analyzer, such as Sweep Rules.
Ref Value
Controls the X value of the selected trace at the chosen X Reference Position.
Remote
Command
:DISPlay:FLATness:WINDow[1]:TRACe:X[:SCALe]:RLEVel <real>
:DISPlay:FLAT:WINDow[1]:TRACe:X[:SCALe]:RLEVel?
Example
:DISP:FLAT:WIND:TRAC:X:RLEV 1
:DISP:FLAT:WIND:TRAC:X:RLEV?
Couplings If Auto Scaling is On, this value is automatically determined by the measurement result. When a value is
set manually, Auto Scaling is automatically set to Off.
Preset If Radio Std is 802.11a/g-ERP-OFDM/g-DSSS-OFDM: -26 Carr
If Radio Std is 802.11n 20MHz: -28 Carr
If Radio Std is 802.11n 40MHz: -58 Carr
If Radio Std is 802.11ac 20MHz: -28 Carr
If Radio Std is 802.11ac 40MHz: -58 Carr
If Radio Std is 802.11ac 80MHz: -122 Carr
If Radio Std is 802.11ac 160MHz: -250 Carr
If Radio Std is 802.11ah 1MHz: -13 Carr
If Radio Std is 802.11ah 2MHz: -28 Carr
If Radio Std is 802.11ah 4MHz: -58 Carr
If Radio Std is 802.11ah 8MHz: -122 Carr
If Radio Std is 802.11ah 16MHz: -250 Carr
If Radio Std is 802.11ax 20MHz: -122 Carr
1533 WLAN Mode User's &Programmer's Reference
