3 WLAN Mode
3.12 IQ Waveform Measurement
Marker Mode
Sets the marker control mode to POSition, DELTa, or OFF. All interactions and
dependencies detailed under the control description are enforced when the remote
command is sent. If the selected marker is OFF, pressing Marker sets it to POSition
(Normal) and places it at the center of the screen on the trace determined by the
Marker Trace rules. At the same time, Marker X-Axis Value appears on the Active
Function area.
The default active function is the active function for the currently selected marker
control mode. If the current control mode is OFF, there is no active function, and the
active function is turned off.
Remote
Command
:CALCulate:WAVeform:MARKer[1]|2|…|12:MODE POSition | DELTa | OFF
:CALCulate:WAVeform:MARKer[1]|2|…|12:MODE?
Example
:CALC:WAV:MARK:MODE OFF
:CALC:WAV:MARK:MODE?
Preset
OFF
State Saved Saved in instrument state
Range
POSition|DELTa|OFF
Annotation Mkr # <X value> and <Marker value> upper right on graph
When Marker Trace is Polar in WCDMA mode:
Mkr # <Chip Value (RHO & QPSKEVM)/Symbol Value (CDP)>, <X value> and <Y value> upper right on
graph
Backwards Compatibility SCPI Command
Sets or queries the state of a marker. Setting a marker that is OFF to state ON or 1
puts it in POSition mode and places it at the center of the screen.
Preset
OFF
State Saved Saved in instrument state
Range
OFF|ON
Backwards
Compatibility
SCPI
:CALCulate:WAVeform:MARKer[1]|2|…|12:STATe OFF | ON | 0 | 1
:CALCulate:WAVeform:MARKer[1]|2|…|12:STATe?
Delta Marker (Reset Delta)
Pressing this control has the same effect as pressing the DELTa selection in "Marker
Mode" on page 1816. The selected marker becomes a Delta marker. If the selected
WLAN Mode User's &Programmer's Reference 1816
