3 WLAN Mode
3.6 Modulation Analysis Measurement
5.
Whether the remote analyzer has B40 option or not.
6.
Whether the HW of the remote analyzer can support MIMO or not.
Remote
Command
:SYSTem:COMMunicate:ANALyzer:VERify <address string>
Example
:SYST:COMM:ANAL:VER “146.208.172.102:5025”
Notes The parameter of the SCPI command is the IP address and SCPI socket port number of the analyzer in
the remote analyzer list
If the parameter in an invalid IP address and SCPI socket port, for example an IP address with a wrong
format or not in the list of the remote analyzers, an error message will be generated, for example,
“Invalid IP address and SCPI socket port 0.0.0.0:0000”
Use the command “SYSTem:COMMunicate:ANALyzer:INFormation?” to obtain the result of the
verification
Select Highlighted Analyzer
You can navigate up and down in the list with the up and down arrow keys and can
select any entry by pressing the “Select Highlighted Analyzer” key.
Each time when pressing this key, the local analyzer will take the following actions:
1.
Sets the current analyzer to the highlighted analyzer.
2.
Checks the prerequisites of the highlighted analyzer (firmware version, options,
etc.)
3.
Switch the current Application in the selected remote analyzer to be the remote
Application.
4.
Lock the front panel of the selected remote analyzer.
Remote
Command
:SYSTem:COMMunicate:ANALyzer:SELect[:IPADdress] <address string>
:SYSTem:COMMunicate:ANALyzer:SELect[:IPADdress]?
Example
:SYST:COMM:ANAL:SEL “146.208.172.102:5025”
:SYST:COMM:ANAL:SEL?
returns all the selected analyzer
Notes The parameter of the SCPI command is the IP address and SCPI socket port number of the analyzer in
the remote analyzer list. If command drops SCPI socket number, then default SCPI port number is taken
In the “Analyzer Config” view, if an analyzer is selected successfully, then related “Selected” state will be
“On”, or otherwise its state is “Off”. System will automatically choose one available channel number for
new selected remote analyzer, which is displayed in “Ch” grid view
If the parameter in an invalid IP address, for example an IP address with a wrong format or not in the
remote analyzer list, an error message will be generated, for example, “0.0.0.0 is not a valid IP address.”
1079 WLAN Mode User's &Programmer's Reference
