3 WLAN Mode
3.2 Channel Power Measurement
(or power) limit individually, and the test passes only when both values are lower than the limit
Couplings The value is automatically converted when PSD Unit is changed
Preset WLAN mode or SA mode with WLAN radio standard: 4.00 dBm/MHz
Otherwise: 4.00 dBm/Hz
State Saved Saved in instrument state
Min/Max –/+200.0
Auto Function
Remote
Command
:CALCulate:CHPower:LIMit:PSDensity:STATe OFF | ON | 0 | 1
:CALCulate:CHPower:LIMit:PSDensity:STATe?
Example
:CALC:CHP:LIM:POW:STAT ON
:CALC:CHP:LIM:POW:STAT?
Preset WLAN Mode: ON
All other Modes: OFF
State Saved Yes
Range
OFF|ON
Power Limit Fail (Remote Query Only)
Queries whether a power test passes or fails. When DVB-T radio standard is
selected in SA Mode, the result of this query has no meaning.
While implementing the scpi, don’t try to remove the SCPI command from the SCPI
tree when DVB-T is selected as current radio standard.
Remote
Command
:CALCulate:CHPower:LIMit:POWer:FAIL?
Example
:CALC:CHP:LIM:POW:FAIL?
Notes Query only
When "Power Limit" on page 279 state is OFF, the returned value is always 0 (pass)
When Power Limit state is ON, the returned value is 0 (pass) if power test passes and 1(fail) if power test
fails
PSD Limit Fail (Remote Query only)
Queries whether PSD test passes or fails. When DVB-T radio standard is selected in
SA Mode, the result of this query has no meaning.
While implementing the scpi, don’t try to remove the SCPI command from the SCPI
tree when DVB-T is selected as current radio standard.
281 WLAN Mode User's &Programmer's Reference
