3 WLAN Mode
3.8 Power vs Time Measurement
Info BW
Enables you to specify the information bandwidth for the analyzer. This is used to set
the hardware filter of the ADC.
Remote
Command
[:SENSe]:PVTime:BANDwidth[:RESolution] <freq>
[:SENSe]:PVTime:BANDwidth[:RESolution]?
Example
:PVT:BAND 6 MHz
:PVT:BAND?
Preset if Radio Std is 802.11a/b/g = 25 MHz
if Radio Std is 802.11n-20M, 802.11ac-20M or 802.11ax-20M = 25 MHz
if Radio Std is 802.11n-40M, 802.11ac-40M or 802.11ax-40M = 4 0MHz
if Radio Std is 802.11ac-80M, 802.11ax-80M, 802.11ac-80M+ 80M or 802.11ax-80M+ 80M= 80 MHz
if Radio Std is 802.11ac-160M or 802.11ax-160M = 160 MHz
other Radio Std = 25 MHz
This parameter is also hardware dependent.
State Saved Yes
Min 1 kHz
Max Analyzer Max Info BW
The analyzer’s max info bandwidth is option dependent:
VXT model M9421A:
No Option = 40.0 MHz
Option B40 = 40.0 MHz
Option B85 = 80.0 MHz
Option B1X = 160.0 MHz
Option U-B85 = Upgrade from 40.0 MHz to 80.0 MHz
Option U-B1X = Upgrade from 80.0 MHz to 160.0 MHz
VXT models M9410A/11A:
Option B40 = 40.0 MHz
M941xA-B3X = 300.0 MHz
M941xA-B6X = 600.0 MHz
M94xA-B12 = 1.2 GHz
M94xAU-B6X = Upgrade from 300.0 MHz to 600.0 MHz
M94xAU-B12 = Upgrade from 300.0 MHz to 1.2 GHz
M94xAU-BU1 = Upgrade from 600.0 MHz to 1.2 GHz
VXT models M9415A:
M9415A-B4X = 400.0 MHz
M9415A-B8X = 800.0 MHz
M9415A-B12 = 1.2 GHz
1357 WLAN Mode User's &Programmer's Reference
