3 WLAN Mode
3.7 WLAN MIMO Modulation Analysis Measurement
Pause/Resume
Pauses a measurement after the current data acquisition is complete.
When paused, the label on the control changes to Resume. Pressing Resume un-
pauses the measurement. When paused, pressing Restart performs a Resume.
Remote Command
:INITiate:PAUSe
:INITiate:RESume
Example
:INIT:PAUS
:INIT:RES
Dependencies Not displayed in Modes that do not support pausing
Annotation Only on control
3.7.10.2 X Scale
This tab accesses controls that enable you to set the horizontal scale parameters.
Ref Value
Sets the X reference value.
Remote
Command
:DISPlay:EVMMimo:WINDow[1]|2|…|9:TRACe:X[:SCALe]:RLEVel <real>
:DISPlay:EVMMimo:WINDow[1]|2|…|9:TRACe:X[:SCALe]:RLEVel?
Example
:DISP:EVMM:WIND:TRAC:X:RLEV 10
:DISP:EVMM:WIND:TRAC:X:RLEV?
Couplings If Auto Scaling is set to On, this value is automatically determined by the measurement result. When
you set this value manually, Auto Scaling automatically changes to Off
Preset See table below
State Saved Yes Saved in instrument state
Min/Max See table below
Table of Ref Value parameters
Group Result Min Max Unit
Terminat
or
Default Knob
Increme
nt
Step Key
Increme
nt
Demod EVM vs.
Carrier
-2048 2048 Carr -28 1 10
WLAN Mode User's &Programmer's Reference 1300
