3.8 Power vs Time Measurement
Marker Operation No
Corresponding Trace None
Metrics window contains results of power-on ramp and power-down ramp.
Name Type Description Unit Format
Mean Power float64 Average power of burst in active
part.
dBm XX.XX dBm
Burst Width float64 Burst determined from ramp up
and ramp down.
us XX.XX us
Ramp Up Time float64 The duration of rising part of burst us XX.XX us
Ramp Up Start
Level
float64 The start level for rising part of
burst
dBm XX.XX dBm
Ramp Up Stop
Level
float64 The stop level for rising part of
burst
dBm XX.XX dBm
Ramp Down
Time
float64 The duration of falling part of burst us XX.XX %
Ramp Down
Start Level
float64 The start level for falling part of
burst
dBm XX.XX dBm
Ramp Down
Stop Level
float64 The stop level for falling part of
burst
dBm XX.XX dBm
3.8.2 Amplitude
3.8.2.1 Y Scale
Contains controls that pertain to the Y axis parameters of the measurement. These
parameters control how data on the vertical (Y) axis is displayed and control
instrument settings that affect the vertical axis.
Ref Value
Sets the value for the absolute power reference. The reference line is at the top,
center, or bottom of the graticule, depending on the value of the Ref Position
function.
Remote
Command
:DISPlay:PVTime:WINDow[1]|2|3:TRACe:Y[:SCALe]:RLEVel <real>
:DISPlay:PVTime:WINDow[1]|2|3:TRACe:Y[:SCALe]:RLEVel?
Window numbers are as follows:
Burst: 1
Rise: 2
