3 WLAN Mode
3.8 Power vs Time Measurement
Window Number
RF Envelope 1
Rise 2
Fall 3
Metrics 4
3.8.1.1 RF Envelope
The RF Envelope window appears in the following View:
View Size Position
Burst Half, full Width Upper
3.8.1.2 Rise
This Rise window appears in the following View:
View Size Position
Rise & Fall Two thirds, half Width Upper left
Marker Operation Yes
Corresponding Trace n=2 waveform of Power-On Ramp
3.8.1.3 Fall
The Fall window appears in the following View:
View Size Position
Rise & Fall Two thirds, half Width Upper right
Marker Operation Yes (Chips - EVM)
Corresponding Trace n=3 waveform of Power-Down Ramp
3.8.1.4 Metrics
The Metrics window appears in the following View:
View Size Position
Burst
Rise & Fall
One third, full width Lower
