3 WLAN Mode
3.7 WLAN MIMO Modulation Analysis Measurement
Example
:CALC:EVMM:TBAS:DCM ON
:CALC:EVMM:TBAS:DCM?
Notes Only be available when Radio Std is 802.11ax/be
Preset Off
State Saved Saved in instrument state
Range On|Off
Backwards Compatibility
SCPI
:CALCulate:EVMMimo:AX:TBASed:DCM ON | OFF | 1 | 0
:CALCulate:EVMMimo:AX:TBASed:DCM?
Max Power of MCS7
This is available only when Radio Std is 802.11ax/be.
This parameter is used to select the EVMM limit.
Remote Command
:CALCulate:EVMMimo:MAXPower:MCS7 <rel_ampl>
:CALCulate:EVMMimo:MAXPower:MCS7?
Example
:CALC:EVMM:MAXP:MCS7 -10
:CALC:EVMM:MAXP:MCS7?
Notes Only available for 11ax/be
Preset -10 dBm
State Saved Saved in instrument state
Min -200
Max 100
Backwards Compatibility
SCPI
:CALCulate:EVMMimo:AX:MAXPower:MCS7 <rel_ampl>
:CALCulate:EVMMimo:AX:MAXPower:MCS7?
3.7.9.9 Advanced
The Advanced tab contains controls for setting advanced function s of the analyzer.
Dependencies This tab does not appear in EXM or VXT
PhNoise Opt
Allows you to select the LO (local oscillator) phase noise behavior for various
operating conditions
Remote Command
[:SENSe]:EVMMimo:FREQuency:SYNThesis[:STATe] 1 | … | 5
[:SENSe]:EVMMimo:FREQuency:SYNThesis[:STATe]?
