3 WLAN Mode
3.6 Modulation Analysis Measurement
Example
:EVM:DEM:RSYM 1
:EVM:DEM:RSYM?
Notes If this is set to On, but no Reference Symbols have been specified or loaded, the warning message
"Please load Reference Symbols" will be displayed
Dependencies The key is blank when the following conditions are met at the same time:
Radio std Detection = Manual
Radio = 802.11a/b/g/j/p
Preset
OFF
State Saved Saved in instrument state
Backwards
Compatibility SCPI
[:SENSe]:EVM:DEMod:REFSymbols ON | OFF | 1 | 0
[:SENSe]:EVM:DEMod:REFSymbols?
Set Reference Symbols (Remote Command only)
Directly specifies I/Q data for Reference Symbols used in EVM measurement. (An
alternative method is to load the data from a file; see Recall Reference
Symbols@1600057.)
Remote Command
[:SENSe]:EVM:DEMod:LIST:RSYMbols I,Q,I,Q…
[:SENSe]:EVM:DEMod:LIST:RSYMbols?
Example
:EVM:DEM:LIST:RSYM 1.0,2.0,3.0,4.0
:EVM:DEM:LIST:RSYM?
Backwards Compatibility
SCPI
[:SENSe]:EVM:DEMod:LIST:REFSymbols I,Q,I,Q…
[:SENSe]:EVM:DEMod:LIST:REFSymbols?
3.6.8.6 IQ Comp
Provides the capability to control separate compensation function explicitly.
Subcarrier I/Q Estimation
This parameter is available when Radio Std is 802.11n/ah/ac/ax/be.
Allows you to turn On or Off the estimation for IQ Gain Imbalance vs. subcarrier, IQ
Quadrature Error vs. subcarrier in the input signal.
Remote
Command
:CALCulate:EVM:IQEStimation OFF | ON | 0 | 1
:CALCulate:EVM:IQEStimation?
Example
:CALC:EVM: IQES ON
:CALC:EVM: IQES?
