3 WLAN Mode
3.5 Spurious Emissions Measurement
3.5.1.2 All Ranges
Windows: "Graph" on page 676,
Select All Ranges to view measurement results for all the ranges.
–
The upper window displays a merged trace of all the ranges
–
The lower window displays a list of spurs detected in a measurement cycle. The
currently selected spur, which is highlighted, can be changed by the Spur
control in the Meas Setup menu
Example
:DISP:SPUR:VIEW ALL
3.5.2 Windows
The following windows are available in this measurement:
1.
"Graph" on page 676
2.
"Table" on page 677
3.
"All Range Table" on page 678
4.
"Gate" on page 679
5.
"Marker Table" on page 679
The Gate Window is available only when "Gate View On/Off" on page 2494 is ON in
Gate Settings under Trigger.
3.5.2.1 Graph
Window #1 & #3
Appears in several Views, as follows:
View Size Position
Graph + Metrics Three fifth, full width Top
All Ranges Three fifth, full width Top
Gate View One third, full width Middle
When Graph + Metrics is selected
WLAN Mode User's &Programmer's Reference 676
