3 WLAN Mode
3.9 Spectral Flatness Measurement
3.9.4.1 Settings
The Settings tab contains the basic Bandwidth functions.
Info BW
Enables you to specify the information bandwidth for the analyzer. This is used to set
the hardware filter of the ADC.
Remote
Command
[:SENSe]:FLATness:BANDwidth[:RESolution] <freq>
[:SENSe]:FLATness:BANDwidth[:RESolution]?
Example
:FLAT:BAND 6 MHz
:FLAT:BAND?
Preset if Radio Std is 802.11a/b/g: 25MHz
if Radio Std is802.11n 20MHz : 25MHz
if Radio Std is802.11n 40MHz : 40MHz
if Radio Std is802.11ac 20MHz : 25MHz
if Radio Std is802.11ac 40MHz : 40MHz
if Radio Std is802.11ac 80MHz : 80MHz
if Radio Std is802.11ac 160MHz : 160MHz
if Radio Std is 802.11ah-1MHz : 3MHz
if Radio Std is 802.11ah-2M : 3MHz
if Radio Std is 802.11ah-4M : 4MHz
if Radio Std is 802.11ah-8M : 8MHz
if Radio Std is 802.11ah-16M: 16MHz
if Radio Std is 802.11j/p-10M: 10MHz
if Radio Std is 802.11p-5M: 5MHz
If Radio Std is 802.11af 6M or 802.11af 7M: 5.3333MHz
If Radio Std is 802.11af 8M: 7.1111MHz
if Radio Std is802.11ax/be 20MHz : 25MHz
if Radio Std is802.11ax/be 40MHz : 40MHz
if Radio Std is802.11ax/be 80MHz : 80MHz
if Radio Std is802.11ax/be 160MHz : 160MHz
if Radio Std is802.11be 320MHz : 320MHz
State Saved Saved in instrument state.
Min/Max 1 kHz/The analyzer’s Max Info Bandwidth is dependent on the BW options:
VXT model M9421A:
No Option = 40.0 MHz
Option B40 = 40.0 MHz
1463 WLAN Mode User's &Programmer's Reference
