3 WLAN Mode
3.6 Modulation Analysis Measurement
Preset 1
Min 1
3.6.8.13 Enable MAC Header Decoding (Remote Command Only)
Specifies whether the MAC header should be decoded or not.
Remote
Command
:CALCulate:EVM:DECode:MACHeader 1 | 0 | ON | OFF
:CALCulate:EVM:DECode:MACHeader?
Example
:CALC:EVM:DEC:MACH 1
:CALC:EVM:DEC:MACH?
Notes This command is available only when the N9077A-AFP license is installed
If “Enable MAC Header Decoding” is ON, it will have a significant impact on the demod speed. Unless it
is necessary, it should be set to be OFF
Preset
OFF
Range On | Off
3.6.8.14 Fast Power Calibration State (Remote Command Only)
To accelerate the calibration speed of MIMO OFDM signals, a new algorithm is
developed to estimate the power of each channel by measuring the combined
power of these channels. This parameter turns on the Fast Power Calibration
calculation.
Remote
Command
[:SENSe]:EVM:PCALibrate 0 | 1 | OFF | ON
[:SENSe]:EVM:PCALibrate?
Notes This parameter takes effect when the Radio Std is 802.11ac/802.11ax (20/40/80/160MHz) and “WLAN
Preamble Puncturing Mode” license is present
When it is On, result index 38 returns the channel power values. The channel number is decided by
MIMO Tx Channel. All the other EVM results are meaningless;
When it is Off, Result index 38 returns -999.0. All the other EVM results are meaningful
Preset
OFF
Range On | Off
3.6.9 Sweep
Contains controls which allow you to control the sweep and measurement functions
of the analyzer, such as the sweep or measurement time and whether in Single
sweep/measure or Continuous sweep/measure mode.
