Keysight M9421A - Scale;Div; Ref Position

3 WLAN Mode
3.4 SEM Measurement
If you set this value manually, Auto Scaling automatically changes to OFF
Preset 1.0 GHz
State Saved Saved in instrument state
Min -1000 GHz
Max 1000 GHz
Backwards
Compatibility
SCPI
:DISPlay:SEMask:VIEW[1]:WINDow[1]:TRACe:X[:SCALe]:RLEVel
Scale/Div
Sets the horizontal scale.
Remote
Command
:DISPlay:SEMask:WINDow[1]:TRACe:X[:SCALe]:PDIVision <freq>
:DISPlay:SEMask:WINDow[1]:TRACe:X[:SCALe]:PDIVision?
Example
:DISP:SEM:WIND:TRAC:X:PDIV 500
:DISP:SEM:WIND:TRAC:X:PDIV?
Couplings If Auto Scaling is ON, this value is automatically determined by the measurement result. When you set
this value manually, Auto Scaling automatically changes to OFF
Preset Automatically Calculated
State Saved Yes Saved in instrument state
Min 1 Hz
Max 100 GHz
Backwards
Compatibility
SCPI
:DISPlay:SEMask:VIEW[1]:WINDow[1]:TRACe:X[:SCALe]:PDIVision
Ref Position
Sets the reference position for the X axis to Left, Center or Right.
Remote
Command
:DISPlay:SEMask:WINDow[1]:TRACe:X[:SCALe]:RPOSition LEFT | CENTer | RIGHt
:DISPlay:SEMask:WINDow[1]:TRACe:X[:SCALe]:RPOSition?
Example
:DISP:SEM:WIND:TRAC:X:RPOS LEFT
:DISP:SEM:WIND:TRAC:X:RPOS?
Preset
CENTer
State Saved Saved in instrument state
Range Left|Center|Right
Backwards
:DISPlay:SEMask:VIEW[1]:WINDow[1]:TRACe:X[:SCALe]:RPOSition
WLAN Mode User's &Programmer's Reference 650
