3 WLAN Mode
3.7 WLAN MIMO Modulation Analysis Measurement
:DEM:TB:STBC?
Dependencies Available for 802.11ax only
Preset
OFF
State Saved Saved in instrument state
3.7.9.8 Limits
Accesses the Limits menu that allows you to set up the test limit for channel power
or power spectral density.
Edit Limit
Edit Limit is a dialog which is designed to set the measurement test limit.
Edit Common Limit
This page defines the limit for all standards.
Freq Error
Sets a frequency error limit to warn you if the measured maximum frequency error
value exceeds the limit.
Remote
Command
:CALCulate:EVMMimo:LIMit:FERRor <real>
:CALCulate:EVMMimo:LIMit:FERRor ?
Example
:CALC:EVMM:LIM:FERR 15
:CALC:EVMM:LIM:FERR?
Couplings If Radio Std is 802.11n or 802.11ax and Center Frequency for 5 GHz band, freq error limit will be
coupled to 20.0 ppm
Preset 802.11n 2.4GHz Band: 25.0ppm
others: 20.0ppm
State Saved Saved in instrument state
Min 0
Max 500 ppm
Symbol Clock Error
Sets a clock error limit to warn you if the measured maximum clock error value
exceeds the limit.
1263 WLAN Mode User's &Programmer's Reference
