Keysight M9421A - Scale;Div; Ref Position

3 WLAN Mode
3.9 Spectral Flatness Measurement
If Radio Std is 802.11be 80MHz: -500 Carr
If Radio Std is 802.11be 160M: -1012 Carr
If Radio Std is 802.11be 320M: -2036 Carr
State Saved Saved in instrument state.
Min/Max -512.0 Carriers / 512.0 Carriers
Scale/Div
Enables you to set the display Y scale/division value.
Remote
Command
:DISPlay:FLATness:WINDow[1]:TRACe:Y[:SCALe]:PDIVision <time>
:DISPlay:FLATness:WINDow[1]:TRACe:Y[:SCALe]:PDIVision?
Example
:DISP:FLAT:WIND:TRAC:Y:PDIV 1
:DISP:FLAT:WIND:TRAC:Y:PDIV?
Couplings If X Auto Scaling is On, this value is automatically determined by the measurement result. When you set
a value manually, X Auto Scaling automatically changes to Off.
Preset If Radio Std is 802.11a/g-ERP-OFDM/g-DSSS-OFDM: 5.2 Carr
If Radio Std is 802.11n 20MHz: 5.6 Carr
If Radio Std is 802.11n 40MHz: 11.6 Carr
If Radio Std is 802.11ac 20MHz: 5.6 Carr
If Radio Std is 802.11ac 40MHz or 802.11af 6/7/8MHz: 11.6 Carr
If Radio Std is 802.11ac 80MHz: 24.4 Carr
If Radio Std is 802.11ac 160MHz: 50.0 Carr
If Radio Std is 802.11ah 1MHz: 2.6 Carr
If Radio Std is 802.11ah 2MHz: 5.6 Carr
If Radio Std is 802.11ah 4MHz: 11.6 Carr
If Radio Std is 802.11ah 8MHz: 24.4 Carr
If Radio Std is 802.11ah 16MHz : 50.0 Carr
State Saved Saved in instrument state.
Min/Max 0.1 carriers /51.2 carriers
Ref Position
Sets the reference position for the Y axis to the left, center, or right of the display.
Remote
Command
:DISPlay:FLATness:WINDow[1]:TRACe:Y[:SCALe]:RPOSition LEFT | CENTer | RIGHt
:DISPlay:FLATness:WINDow[1]:TRACe:Y[:SCALe]:RPOSition?
Example
:DISP:FLAT:WIND:TRAC:Y:RPOS LEFT
:DISP:FLAT:WIND:TRAC:Y:RPOS?
WLAN Mode User's &Programmer's Reference 1418
