3 WLAN Mode
3.9 Spectral Flatness Measurement
This parameterSymbol Timing Adjust controls how far the FFT part of the symbol is
adjusted away from the end of the symbol time. The value is in terms of percent of
the used (FFT) part of the symbol time.
The value must be between zero (meaning no adjustment) and -100*Guard Interval.
Values outside of that range are clipped to the limit. Note that this parameter value
is negative, because the FFT start time is moved back by this parameter.
Remote Command
[:SENSe]:FLATness:TADJust
<percent>
[:SENSe]:FLATness:TADJust?
Example
:FLAT:TADJ -3.125
:FLAT:TADJ?
Preset -3.125%
State Saved Saved in instrument state.
Min/Max -100.0*Guard Interval / 0.0
Sync Training Sequence
This parameter specifies synchronization method to use when synchronizing to the
start of the OFDM burst. The valid values are Short or Long.
1491 WLAN Mode User's &Programmer's Reference
