Keysight M9421A - 3.4.1 Results for n = 1

3 WLAN Mode
3.4 SEM Measurement
n Results
22
Offset pass/fail (Offset A- L)
Available only in LTEAFDD, LTEATDD, and 5GNR Modes
3.4.1 Results for n = 1
For WLAN Mode, these results apply to all standards except 802.11ac/ax
(80+80MHz).
Returns 82 comma-separated scalar results, in the following order:
k is an index for each offset: k = 0 for offset A; k = 1 for offset B; k = 2 for offset C, etc.
The number of offsets is 6 (A-F).
# Item Unit, if any
1 Reserved for future use, returns -999.0
2 Power
(*1)
at the center frequency (reference) area When "Measurement Type" on page 632 is
PSD Ref: dBm/Hz
Others: dBm
3~4 Reserved for future use, returns -999.0
5 Peak frequency in the center frequency (reference) area Hz
6~10 Reserved for future use, returns -999.0
11
10k + 11,
k = 0
Relative integrated power on the negative offset A
Returns -999.0 when "Measurement Type" on page 632 is
Spectrum Peak Ref
When "Measurement Type" on page 632 is
PSD Ref: dB
When Total Power Ref: dBc
12
10k + 12,
k = 0
Absolute integrated power on the negative offset A
Returns -999.0 when "Measurement Type" on page 632 is
Spectrum Peak Ref
When "Measurement Type" on page 632 is
PSD Ref: dBm/Hz
When Total Power Ref: dBm
13
10k + 13,
k = 0
Relative peak power on the negative offset A When "Measurement Type" on page 632 is
Total Power Ref: dBc
Others: dB
14
10k + 14,
k = 0
Absolute peak power on the negative offset A When "Measurement Type" on page 632 is
PSD Ref: dBm/Hz
Others: dBm
15
10k + 15,
k = 0
Peak power offset frequency from the center or carrier edge
frequency in the negative offset A
Depends on the setting of "Offset Freq Define" on page 574
Hz
16
10k + 16,
k = 0
Relative integrated power on the positive offset A
Returns -999.0 when "Measurement Type" on page 632 is
Spectrum Peak Ref
When "Measurement Type" on page 632 is
PSD Ref: dB
Others: dBc
17 Absolute integrated power on the positive offset A When "Measurement Type" on page 632 is
