Keysight M9421A - Auto Scaling

3 WLAN Mode
3.8 Power vs Time Measurement
Burst: 1
Rise: 2
Fall: 3
Example
:DISP:PVT:WIND:TRAC:Y:RPOS CENT
1-Burst for Transmit On/Off Power
:DISP:PVT:WIND:TRAC:Y:RPOS?
1-Burst for Transmit On/Off Power
:DISP:PVT:WIND2:TRAC:Y:RPOS CENT
2-Rise for Transmit On/Off Power
:DISP:PVT:WIND3:TRAC:Y:RPOS CENT
3-Fall for Transmit On/Off Power
Preset TOP
State Saved Saved in instrument state.
Range Top|Ctr|Bot
Annotation The greater than (>) and less than (<) symbols are displayed on both sides of the graph to indicate the
Reference Position
Backwards Compatibility SCPI
Window Numbers used to be a combination of View and Window, now the VIEW
parameter is not used and defaults to 1. All Windows are referenced through
VIEW1. For backwards compatibility the old View and Window numbers are
honored as below:
Window Old SCPI Command New SCPI Command
PVT - Burst :DISP:PVT:VIEW[1]:WIND:TRAC:Y:RPOS
CENT
:DISP:PVT:WIND[1]:TRAC:Y:RPOS
CENT
PVT – Rise :DISP:PVT:VIEW2:WIND:TRAC:Y:RPOS
CENT
:DISP:PVT:WIND2:TRAC:Y:RPOS
CENT
PVT – Fall :DISP:PVT:VIEW2:WIND2:TRAC:Y:RPOS
CENT
:DISP:PVT:WIND3:TRAC:Y:RPOS
CENT
Auto Scaling
Toggles the Auto Scaling function between On and Off.
Remote
Command
:DISPlay:PVTime:WINDow[1]|2|3:TRACe:Y[:SCALe]:COUPle 0 | 1 | OFF | ON
:DISPlay:PVTime:WINDow[1]|2|3:TRACe:Y[:SCALe]:COUPle?
Window numbers are as follows:
WLAN Mode User's &Programmer's Reference 1316
