3 WLAN Mode
3.6 Modulation Analysis Measurement
Radio Std Value
802.11ac 40 MHz 312.5 kHz
802.11ac 80 MHz 312.5 kHz
802.11ac 80+80 MHz 312.5 kHz
802.11ac 160 MHz 312.5 kHz
802.11ah 1 MHz 31.25 kHz
802.11ah 2 MHz 31.25 kHz
802.11ah 4 MHz 31.25 kHz
802.11ah 8 MHz 31.25 kHz
802.11ah 16 MHz 31.25 kHz
802.11af 6 MHz 41.666667 kHz
802.11af 7 MHz 41.666667 kHz
802.11af 8 MHz 55.555556 kHz
802.11ax 20 MHz, 40 MHz, 80 MHz, 80+80 MHz, 160 MHz 312.5 kHz
802.11be 20 MHz, 40 MHz, 80 MHz, 160 MHz, 320MHz 312.5 kHz
Guard Interval Selection (Radio Std NOT 802.11b/g(DSSS/CCK/PBCC) or 802.11ax/be)
Specifies the guard interval (also called cyclic extension) length for each symbol
time, as a fraction of the FFT length. The value must match the guard interval length
actually used in the input signal in order for demodulation to work properly. The
value should be between zero and one, and values outside that range are clipped to
be within the range. The value is rounded to the nearest 1/128th.
Remote
Command
Radio Std = 802.11a/g/j/p(OFDM 20 MHz)
[:SENSe]:DEMod[:WLAN]:AG:GINTerval R1B4 | R1B8 | OTHer
[:SENSe]:DEMod[:WLAN]:AG:GINTerval?
Radio Std = 802.11g(DSSS-OFDM)
[:SENSe]:DEMod[:WLAN]:GDO:GINTerval R1B4 | R1B8 | OTHer
[:SENSe]:DEMod[:WLAN]:GDO:GINTerval?
Radio Std = 802.11j/p(OFDM 10 MHz)
[:SENSe]:DEMod[:WLAN]:JP10:GINTerval R1B4 | R1B8 | OTHer
[:SENSe]:DEMod[:WLAN]:JP10:GINTerval?
Radio Std = 802.11j/p(OFDM 5 MHz)
[:SENSe]:DEMod[:WLAN]:P5:GINTerval R1B4 | R1B8 | OTHer
[:SENSe]:DEMod[:WLAN]:P5:GINTerval?
Radio Std = 802.11n 20 MHz
[:SENSe]:DEMod[:WLAN]:N20:GINTerval R1B4 | R1B8 | SIG | OTHer
989 WLAN Mode User's &Programmer's Reference
