3 WLAN Mode
3.8 Power vs Time Measurement
:DISP:PVT:RAMP?
Preset ON
State Saved Yes
Range On|Off
3.8.4.2 Views
The Power vs. Time measurement has 2 views as follows.
NO. View NO. of Windows Window No. Window
1 Burst Dual 1 RF Envelope
2 Metrics
2 Rise & Fall Triple 1 Rise
2 Fall
3 Metrics
These Views are multiple-window Views. When in a multiple window View, you
select a window by touching it. The menu controls may sometimes change
depending on which window is selected.
Whenever the View changes, the default menu is Frequency, unless otherwise
specified in the View description.
You can select the desired measurement view from the selections listed in the table
below. There are two available commands, allowing you to select the view using
either a string ID or a numeric ID value.
–
:DISP:PVT:VIEW[:SEL] <string ID>
–
:DISP:PVT:VIEW:NSEL <numeric ID>
View
Name
String ID Numeric ID View Description
Burst ALL 1 Provides RF Envelope for a WLAN modulated burst
and the Numeric Results data.
Rise & Fall BOTH 2 Provides RF Power Ramp Up and Ramp down traces
and Numeric Results data.
View Selection by Name
Remote Command
:DISPlay:PVTime:VIEW[:SELect] ALL | BOTH
:DISPlay:PVTime:VIEW[:SELect]?
Example
:DISP:PVT:VIEW ALL
:DISP:PVT:VIEW?
1359 WLAN Mode User's &Programmer's Reference
