3 WLAN Mode
3.7 WLAN MIMO Modulation Analysis Measurement
EHT SIG No
For OFDMA transmission or non-OFDMA transmission to multiple users, EHT-SIG
field when BW is greater than 80 MHz contains two EHT-SIG content channels per
80 MHz and the EHT-SIG content channels per 80 MHz are allowed to carry
different information.
You can choose EHT-SIG No to see EHT-SIG filed decoded information for each 80
MHz subblock.
Remote Command
:DISPlay:EVMMimo:EHTSig[:NUMBer] <integer>
:DISPlay:EVMMimo:EHTSig[:NUMBer]?
Example
:DISP:EVMM:EHTS 1
:DISP:EVMM:EHTS?
Preset 1
State Saved Saved in instrument state
Min 1
Max 1 for 11be 20M/40M/80M
2 for 11be 160M
4 for 11be 320M
3.7.6.3 Annotation
Contains controls for setting up the annotation for the current Mode or
Measurement.
Graticule
Turns the display graticule On or Off for all windows with graticules in all
measurements in the current Mode. Also turns the graticule Y-Axis annotation on
and off.
Remote
Command
:DISPlay:GRATicule[:STATe] OFF | ON | 0 | 1
:DISPlay:GRATicule[:STATe]?
Example
:DISP:GRAT OFF
Notes The graticule is the set of horizontal and vertical lines that make up the grid/divisions for the X-Axis and
Y-Axis
Preset
ON
State Saved Saved in instrument state
Backwards
:DISPlay:WINDow[1]:TRACe:GRATicule:GRID[:STATe] OFF | ON | 0 | 1
1179 WLAN Mode User's &Programmer's Reference
