3 WLAN Mode
3.8 Power vs Time Measurement
M9415AU-B6X = Upgrade from 400.0 MHz to 800.0 MHz
M9415AU-B12 = Upgrade from 400.0 MHz to 1.2 GHz
M9415AU-BU2 = Upgrade from 800.0 MHz to 1.2 GHz
All other models:
B1Y=160 MHz, B1X=140 MHz, B1A=125 MHz, B85= 85 MHz, B40=40 MHz, B25=25 MHz, else 10 MHz
When Info BW auto coupled by Radio Std exceeds max BW of hardware, there will be an error
message: Invalid result; Wider BW required.
Backwards
Compatibility
SCPI
[:SENSe]:<meas>:BWIDth[:RESolution]
RBW Filter Type
Toggles the filter shapes between Gaussian and Flat (flattop).
Remote
Command
[:SENSe]:PVTime:BANDwidth:TYPE GAUSsian | FLATtop
[:SENSe]:PVTime:BANDwidth:TYPE?
Example
:PVT:BAND:TYPE FLAT
:PVT:BAND:TYPE?
Preset GAUSsian
State Saved Saved in instrument state
Range Gaussian|Flattop
3.8.4 Display
The Display key opens the Display Menu, which lets you configure display items for
the current Mode, Measurement View or Window.
3.8.4.1 Meas Display
The Meas Display tab contains controls for setting up the display for the current
Measurement, View or Window.
Ramp Lines
Turns the ramp lines On or Off.
Remote Command
:DISPlay:PVTime:RAMP[:STATe] OFF | ON | 0 | 1
:DISPlay:PVTime:RAMP[:STATe]?
Example
:DISP:PVT:RAMP ON
WLAN Mode User's &Programmer's Reference 1358
