3 WLAN Mode
3.7 WLAN MIMO Modulation Analysis Measurement
User MCS
Determines MCS (modulation and coding schema) of each RU.
This is a list parameter, and the length of the list is the number of users.
Remote Command
[:SENSe]:DEMod[:WLAN]:USER:LIST:MCS <integer>,<integer>,<integer>,…
[:SENSe]:DEMod[:WLAN]:USER:LIST:MCS?
Example
:DEM:USER:LIST:MCS 0,11,0,11,0,11,0,11,0
:DEM:USER:LIST:MCS?
Notes The length of the list is variable and determined by the number of RUs
Dependencies Only available for 802.11ax/ 802.11be
Preset 08
State Saved Saved in instrument state
Min 0
Max 13
Spatial Stream Number of Each User
This parameter determines MCS (modulation and coding schema) of each RU.
This is a list parameter, and the length of the list is the number of users.
Remote Command
[:SENSe]:DEMod[:WLAN]:USER:LIST:STReam <integer>,<integer>,<integer>,…
[:SENSe]:DEMod[:WLAN]:USER:LIST:STReam?
Example
:DEM:USER:LIST:STR 1,1
:DEM:USER:LIST:STR?
Notes The length of the list is variable and determined by the number of RUs
Dependencies Only available for 802.11ax/ 802.11be
Preset
1
State Saved Saved in instrument state
Channel Coding Mode of Each User
This parameter determines channel coding mode of each RU.
This is a list parameter, and the length of the list is the number of users.
Remote Command
[:SENSe]:DEMod[:WLAN]:USER:LIST:CCMode BCC | LDPC, BCC | LDPC, BCC | LDPC,…
[:SENSe]:DEMod[:WLAN]:USER:LIST:CCMode?
WLAN Mode User's &Programmer's Reference 1260
