3 WLAN Mode
3.7 WLAN MIMO Modulation Analysis Measurement
[offset < 600 kHz] |
Best Wide-Offset Phase Noise
[offset > 800 kHz] |
Fast Tuning
EP1:
Best Close-In Phase Noise
[offset < 140 kHz] |
Best Wide-Offset Phase Noise
[offset > 160 kHz] |
Fast Tuning
[single loop]
EP2 & EP3:
Best Close-In Phase Noise
[offset < 70 kHz] |
Best Wide-Offset Phase Noise
[offset > 100 kHz] |
Fast Tuning
[medium loop bw]
EP4:
Best Close-In Phase Noise
[offset < 90 kHz] |
Best Wide-Offset Phase Noise
[offset > 130 kHz] |
Fast Tuning
[same as Close-in]
LO Dither
Remote Command
[:SENSe]:EVMMimo:LO:DITHer[:STATe] ON | OFF | 1 | 0
[:SENSe]:EVMMimo:LO:DITHer[:STATe]?
Example
:EVMM:LO:DITH 1
:EVMM:LO:DITH?
Dependencies This feature is only available when the instrument has the option H1G installed
The LO Dither key is turned Off and grayed out when IFBW <= 255M. If the user pressed the grayed-
out key, then a warning message “Feature only available with the H1G path” is shown
If the user tries to set LO Dither to ON via SCPI, a message -221,"Settings conflict; Feature only
available with the H1G path" is returned
Preset 0
