3 WLAN Mode
3.6 Modulation Analysis Measurement
Name Command
Delete All But This Screen
:INSTrument:SCReen:DELete:ALL
Add Screen
:INSTrument:SCReen:CREate
Rename Screen
:INSTrument:SCReen:REName
Sequencer On/Off
:SYSTem:SEQuencer
Remote
Command
:DISPlay:ENABle OFF | ON | 0 | 1
:DISPlay:ENABle?
Example
:DISP:ENAB OFF
Couplings :DISP:ENAB OFF turns Backlight OFF and :DISP:ENAB ON turns Backlight ON, but changing
Backlight settings does not change the state of :DISP:ENAB
Preset
ON
Set by :SYST:DEF MISC, but not affected by *RST or :SYSTem:PRESet
State Saved Not saved in instrument state
Backwards
Compatibility
Notes
:SYST:PRES no longer turns on :DISPlay:ENABle as it did in legacy analyzers
3.6.6 Frequency
Opens the Frequency menu, which contains controls that allow you to control the
Frequency and Channel parameters of the instrument.
Some features in this menu are the same for all measurements in the current Mode
– they do not change as you change measurements. Settings like these are called
“Meas Global” and are unaffected by Meas Preset. For example, the Center Freq
setting is the same for all measurements - it does not change as you change
measurements.
Meas Global settings can be identified by the “Meas Global” in the Scope row in the
SCPI tables.
3.6.6.1 Settings
Contains controls that pertain to the X axis parameters of the measurement. These
parameters control how data on the vertical (X) axis is displayed and control
instrument settings that affect the horizontal axis.
949 WLAN Mode User's &Programmer's Reference
