3 WLAN Mode
3.7 WLAN MIMO Modulation Analysis Measurement
Example
:EVMM:AVER OFF
:EVMM:AVER?
Couplings As Radio Std Detection is set to Auto, Average State is coupled to OFF
Preset
ON
State Saved Saved in instrument state
Range On|Off
Avg Mode
Selects the type of termination control used for the averaging function. This
determines the averaging action after the specified number of data acquisitions
(average count) is reached.
–
Exponential - After the average count is reached, each successive data
acquisition is exponentially weighted and combined with the existing average
–
Repeat - After reaching the average count, the averaging is reset, and a new
average is started
The default value is Exp.
Remote
Command
[:SENSe]:EVMMimo:AVERage:TCONtrol EXPonential | REPeat
[:SENSe]:EVMMimo:AVERage:TCONtrol?
Example
:EVMM:AVER:TCON REP
:EVMM:AVER:TCON?
Preset
EXPonential
State Saved Saved in instrument state
Range Exponential|Repeat
MIMO Type
This parameter specifies the MIMO Type.
Remote
Command
[:SENSe]:EVMMimo:TYPE M1M1 | M2M2 | M3M3 | M4M4 | M6M6 | M8M8
[:SENSe]:EVMMimo:TYPE?
Example
:EVMM:TYPE M3M3
:EVMM:TYPE?
Notes There are constraints on remote analyzer configuration for a selected MIMO type in E6640A. VXT
models have no such restrictions
–
For E6640A:
For MIMO 2x2, valid remote analyzer configurations are as follows:
