3 WLAN Mode
3.4 SEM Measurement
# Item Unit
---
30
2k + 4, k = 13
Power
(*2)
at positive offset N
*1: Ref carrier power when "Measurement Type" on page 632 is Total Power Ref or
PSD Ref; Spectrum peak power when "Measurement Type" on page 632 is
Spectrum Peak Ref
*2: Absolute integrated power when "Measurement Type" on page 632 is Total
Power Ref or PSD Ref; Absolute peak power when "Measurement Type" on page 632
is Spectrum Peak Ref
If the result is not available, -999.0 is returned
The number of values returned is subject to change in future releases
3.4.5 Results for n = 6
When "Measurement Type" on page 632 is Total Power Ref or PSD Ref, returns 30
comma-separated scalar values (in dBc or dBc/Hz) of the integrated power relative
to the carrier at the segment frequencies
When "Measurement Type" on page 632 is Spectrum Peak Ref, returns 30 comma-
separated scalar values (in dB) of the peak power relative to the carrier at the
segment frequencies
k is an index for each offset: k = 0 for offset A; k = 1 for offset B; k = 2 for offset C, etc.
The number of offsets is 14 (A-N).
# Item
1 Reserved for future use, returns -999.0
2 Reserved for future use, returns -999.0
3
2k + 3, k = 0
Power
(*1)
at negative offset A
4
2k + 4, k = 0
Power
(*1)
at positive offset A
---
30
2k + 4, k = 13
Power
(*1)
at positive offset N
*1: Relative integrated power when "Measurement Type" on page 632 is Total Power
Ref or PSD Ref; Relative peak power when "Measurement Type" on page 632 is
Spectrum Peak Ref
If the result is not available, -999.0 is returned
469 WLAN Mode User's &Programmer's Reference
