3 WLAN Mode
3.7 WLAN MIMO Modulation Analysis Measurement
Remote Command
:CALCulate:EVMMimo:MARKer[1]|2|…|12:PTPeak
Example
:CALC:EVMM:MARK:PTP
Notes Turns on the Marker D active function
Sending this command selects the subopcoded marker
Dependencies Pk-Pk Search is not available when Coupled Markers is on
Couplings The selected marker becomes a delta marker if not already in delta mode
State Saved Not saved in instrument state
Marker Delta
Pressing this button is exactly the same as pressing the “Delta” selection on the
Marker Mode radio button on the Settings tab. The selected marker becomes a
Delta Marker. If the selected marker is already a Delta marker, the reference marker
is moved to the current position of the selected marker, thus resetting the Delta to
zero.
The control is duplicated here in the Peak Search menu to allow you to conveniently
perform a peak search and change the marker’s control mode to Delta without
having to access two separate menus.
3.7.8.4 Properties
The controls on the Properties tab are used to set certain properties of the selected
marker.
Marker X
See "Marker X" on page 1186 control on the Settings tab.
Relative To
Selects the marker to which the selected marker is relative (its reference marker).
Every marker has another marker to which it is relative. This marker is referred to as
the “reference marker” for that marker. This attribute is set by the Marker,
Properties, Relative To key. The marker must be a Delta marker to make this
attribute relevant. If it is a Delta marker, the reference marker determines how the
marker is controlled and how its value is displayed. A marker cannot be relative to
itself.
Remote
Command
:CALCulate:EVMMimo:MARKer[1]|2|…|12:REFerence <integer>
:CALCulate:EVMMimo:MARKer[1]|2|…|12:REFerence?
WLAN Mode User's &Programmer's Reference 1194
