3 WLAN Mode
3.4 SEM Measurement
# Item Unit
= 0 Others: dB
9
10k + 9, k
= 0
Absolute peak power on the positive offset A When "Measurement Type" on page 632 is
PSD Ref: dBm/Hz
Others: dBm
10
10k + 10,
k = 0
Peak power offset frequency from the center or carrier edge
frequency in the positive offset A
Depends on the setting of "Offset Freq Define" on page 574
Hz
---
140
10k + 10,
k = 13
Peak power offset frequency from the center or carrier edge
frequency in the positive offset N
Depends on the setting of "Offset Freq Define" on page 574
Hz
If the result is not available, NaN (9.91E+37) is returned
The number of values returned is subject to change in future releases
3.4.9 Results for n = 15
Results available only when "Measurement Type" on page 632 is Total Power
Reference.
Returns comma-separated scalar results, in the following order:
k is an index for each offset: k = 0 for offset A; k = 1 for offset B; k = 2 for offset C, etc.
The number of offsets is 14 (A-N).
# Item Unit
1
2k + 1, k = 0
Minimum margin from limit line on the negative offset A dB
2
2k + 2, k = 0
Minimum margin from limit line on the positive offset A dB
3
2k + 1, k = 1
Minimum margin from limit line on the negative offset B dB
4
2k + 2, k = 1
Minimum margin from limit line on the positive offset B dB
---
28
2k + 2, k = 13
Minimum margin from limit line on the positive offset N dB
If the result is not available, NaN (9.91E+37) is returned
The number of values returned is subject to change in future releases
