3 WLAN Mode
3.7 WLAN MIMO Modulation Analysis Measurement
More Information
Here is the detail for parameters in the dialog box.
Value SCPI Unit of
returned
Notes
Peak Power
:CALCulate:EVM:LEVel:PEAK?
:CALC:EVM:LEV:PEAK?
dBm Queries the peak
power of the burst
Trigger Level
:CALCulate:EVM:LEVel:TRIGger?
:CALC:EVM:LEV:TRIG?
dBm Queries the
recommended
video trigger level
Max Packet
Length
:CALCulate:EVM:LEVel:TIME?
:CALC:EVM:LEV:TIME?
second Queries the max
packet length
Max
Symbol/Chip
Used
:CALCulate:EVM:LEVel:POINt?
:CALC:EVM:LEV:POIN?
None Queries the
number of the
max symbol/chip
used in the burst.
For 11b/g, this
value is the total
number of chips.
For OFDM format,
this value is the
total number of
symbols
Auto Couple
Immediately puts all Auto/Man functions into Auto. Auto Couple is confined to the
current measurement only. It does not affect other measurements in the Mode.
In the Auto state, Auto/Man functions are said to be “coupled”, meaning their values
change as you make changes to other values in the measurement. This helps ensure
accurate measurements and optimum dynamic range. Auto Couple is an immediate
action function, and when it is executed, all the Auto/Man controls for the current
measurement are set to Auto, and all measurement settings coupled to the
Auto/Man parameters are automatically set to their optimal values.
For further details of measurement-specific settings (if any), see "Measurement-
Specific Details" on page 1205 below.
Remote
Command
:COUPle ALL
Example
:COUP ALL
Backwards
Compatibility
SCPI
:COUPLE ALL | NONE
WLAN Mode User's &Programmer's Reference 1204
